Fused Silica

Fused Silica

Fused Silica


Fused Silica is made of high purity quartz sand by electrically fused in electric arc furnaces, then the crystalline quartz sand transformed into amorphous silicon dioxide.

Email: [email protected]

Product detail

Fused Silica

Main Composition:SiO2

Raw Material:Quartz sand

Capacity:1000 tons per month

Color:White

Size:As your requirements

Product Introduction

Fused Silica is made of high purity quartz sand by electrically fused in electric arc furnaces, then the crystalline quartz sand transformed into amorphous silicon dioxide.

Features

1.Low thermal conductivity.

2.Low thermal expansion.

3.Small heat capacity.

Application

Mainly used for manufacturing glass, refractory materials, smelting ferrosilicon, coatings, rubber fillers, metallurgical flux, ceramics, abrasive materials, and also for metal surface treatment. In construction, it can be used to make acid-resistant concrete and acid-resistant mortar because of its strong resistance to acid media.

Product Parameters

Type AGuaranteed Value BGuaranteed Value
SiO2 99.9%min 99.8%min
 Al2O3 200ppm max 300ppm max
Fe2O3 50ppm max 50ppm max
Bulk Density 3.3 g/cm3min 3.2 g/cm3min
Sizes 0-40/20-10/8-5/5-3/3-1/1-0mm
4-10/10-20/20-50/50-100mesh
Fines -100/-200/-325mesh
Test standard GB/T3284-1993
