Graphite Block

Graphite Block

Graphite Block utilizes low ash synthetic graphite, high quality petroleum coke and pitch coke primary material, along with additive. Graphite block is molded under high pressure, impregnated, baked, graphitized and then machined to specification.

Graphite Block features excellent thermal conductivity that leads to better cooling.
Density: 1.6g/cm3-1.9g/cm3
Grain Size: 8mm, 4mm, 2mm, 0.8mm, 325mesh.
Production: Isostatic, molded, extruded, vibrated.
Characteristics: low electric resistance, good electric and thermal conductivity, high oxidation resistance, greater resistance to thermal and mechanical shock, high mechanical strength, high machining accuracy and so on.

Graphite Block Include:
Medium Coarse Graphite Block
High Purity Graphite Block
Isostatic Graphite Block
